Truck-Mounted Drilling Rig
The truck-mounted drilling rigs TS-SINOTAI supplies conform to API standards. They have characteristic of strong mobility, saving mobilization cost and meeting the request of fast installation.
Modularized, highly integrated, fast-moving, fast installation.
A hammer and a special pin-pulling tool are enough for the rigging-down, thus the operation is safe and reliable.
K-type vertical mast raised by hydraulic cylinder as a whole, two-stage telescoping, high load-bearing capacity.
The parallelogram substructure, driller side base driller opposite side base and intermediate connecting part are respectively installed on a skid and transported independently multiple draw bar connection, low-position installation raised as a whole.
Digital control technology, independent drive drawworks and rotary table, reliable operation.
The combination of band brake, pneumatic disc brake and computer-controlled auto driller ensure high efficient operation.
Standardized interface will make installation and movement of rig modules easy and convenient.
Description | XJ750 (150T) | XJ650 (120T) | XJ550 (100T) | XJ450 (80T) | XJ350 (60T) | XJ300 (50T) | XJ250 (40T) | XJ150 (30T) | ||
Minor overhaul depth | Φ73mm (2 7/8” EUE tubing) | m | - | 8500 | 7000 | 5500 | 4000 | 3600 | 3200 | 2600 |
Overhaul depth | Φ73mm( 2 7/8”DP) | m | 8000 | 7000 | 5800 | 4500 | 3200 | 2600 | 2000 | 1500 |
Φ88.9mm( 3 1/2”DP) | m | 6500 | 5500 | 4500 | 3500 | 2500 | 2300 | - | - | |
Φ114mm(4 1/2”DP) | m | 5000 | 4200 | 3600 | - | - | - | - | ||
Drilling depth | m | 3000 | 2000 | 1500 | 1200 | 800 | 700 | 600 | - | |
Rated hook load | KN | 1500 | 1200 | 1000 | 800 | 600 | 500 | 400 | 300 | |
Max. hook load | KN | 1800 | 1580 | 1350 | 1125 | 900 | 750 | 700 | 585 | |
Engine model | CAT C15 X 2 | CAT C18 | CAT C15 | CAT C15 | CAT C9 | CAT C9/ WP10G336E341 | WP10.336E53 | WP10.300 | ||
Engine power | KW(HP) | 403(540) X 2 | 470(630) | 403(540) | 354(475) | 261(350) | 261(350)/ 250(336) | 250(336) | 216(290) | |
Transmission | Allision M5620AR X 2 | Allision M6620AR | Allision M5620AR | Allision M5620AR | Allision 4700 OFS | Allision 4700/4430 OFS | YJ409Gc | YJ409Gc | ||
Chassis driving form | 14x8 | 12x8 | 10x8 | 10x8 | 10x8/8x4 | 10x8/8x4 | 8x8/8x6/6x6 | 6x4 | ||
Approach/departure | 33°/ 17° | 25°/ 16° | 25°/ 16° | 25°/ 16° | 25°/ 16° | 25°/ 16° | 25°/ 16° | 25°/ 16° | ||
Min. ground clearance | mm | 310 | 310 | 310 | 310 | 310 | 310 | 310 | 310 | |
Derrick height | m | 38 | 35 | 33 | 33/31.7 | 31.7/21 (No-guyline) | 29/21 (No-guyline) | 29/17/21 (No-guyline) | 17/18 | |
Derrick type | Front opened, double section, telescope mast | Front opened, double/single mast | ||||||||
Valid rope number | 10(6X5) | 8(5x4) | 8(5x4) | 8(5x4) | 6(4x3) | 6(4x3) | 6(4x3) | 6(4x3) | ||
Hoist rope diameter | mm | φ32/φ29 | φ29 | φ26 | Φ26 | φ26 | φ26 | φ22 | φ22/φ19 | |
Transportation dimensions(L x W x H) | m | 24.00X3.30X4.5 | 20.12X2.95X4.4 | 18.50X2.85X4.20 | 18.50X3.03X4.20 | 18.50X2.90X4.20 | 16.90X2.50X4.30 | 12.94X2.44X4.00 | 14.30X2.44X3.80 | |
Total weight | kg | 76000 | 55000 | 53000 | 51500 | 51000 | 36000 | 27380 | 23000 | |
Drum | Single / double drum | |||||||||
Main drum assist brake system | Air control disk brake / hydraulic disc brake / Water brake | |||||||||
